Wave Energy Devices

Devices that Harness the Energy of the Waves

wave energy iconThe amount of power available in the movement of ocean waves has inspired many engineers to develop machines and devices to capture and use this free oceanic power. In certain parts of the world’s oceans the amount of wave energy is vast, so the development of wave energy devices to exploit the the inherent oscillatory nature of ocean waves for electrical energy generation.

We have seen previously that Wave Energy is a non-polluting and renewable source of energy, created by natural transfer of wind energy above the oceans, which itself is created by the effects of the suns solar energy. As the wind blows across the oceans surface, moving air particles transfer their energy to the water molecules that they touch.

As the wind continues to blow more and more of its kinetic energy is transferred to the oceans surface and the waves grow bigger. These larger waves are called gravity waves because their potential energy is due to the gravitational force of the Earth. There is a lot of potential energy in the waves generated by the wind, to the point were large storm waves can lift ships high out of the water.

As an ocean wave passes a stationary position the surface of the sea changes in height, water near the surface moves as it losses its kinetic and potential energy, which affects the pressure under the surface. The periodic or oscillatory nature of ocean waves means that we can use a variety of different Wave Energy Devices to harness the energy produced by the oceans waves.

The problem lies in that the oscillatory frequency of an ocean wave is relatively slow and is much less than the hundreds of revolutions per minute required for electric power generation. Then a great variety of wave energy devices and designs are available to convert these slow-acting, reversing wave forces into the high speed, unidirectional rotation of a generator shaft.

There are three fundamental but very different wave energy devices used in converting the ocean wave power into electric power, and these are:

  • Wave Profile Devices These are wave energy devices which turn the oscillating height of the oceans surface into mechanical energy.
  • Oscillating Water Columns These are wave energy devices which convert the energy of the waves into air pressure.
  • Wave Capture Devices These are wave energy devices which convert the energy of the waves into potential energy.

Wave Profile Devices

Wave profile devices are a class of wave energy device which floats on or near to the sea surface and moves in response to the shape of the incident wave or, for submersible devices, it moves up and down under the influence of the variations in underwater pressure as a wave moves by.

Most types of wave profile devices float on the surface absorbing the wave energy in all directions by following the movements of waves at or near the sea surface, just like a float. The only wave energy devices that use wave profiling have been in practical use for some time, although on a fairly small-scale, are those used for powering navigation buoys.

If the physical size of the wave profile device is very small compared to the periodic length of the wave, this type of wave energy device is called a “point absorber”. If the size of the device is larger or longer than the typical periodic wavelength, it is called a “linear absorber”, but more commonly they are collectively known as “wave attenuators”.

The main difference between the two wave energy devices is how the oscillating system converts the wave energy between the absorber and a reaction point. This energy absorption can be achieved either by a floating body, an oscillating solid member or oscillating water within a buoys structure itself.

The waves energy is absorbed using vertical motion (heave), horizontal motion in the direction of wave travel (surge), angular motion about a central axis parallel to the wave crests (pitch) or angular motion about a vertical axis (yaw) or a combination of all four with the energy being generated by reacting these different movements against some kind of fixed resistance called a reaction point.

To make efficient use of the force generated by the wave, we need some kind of force reaction. In other words, we want the waves force on the float to react against another rigid or semi-rigid body. Reaction points can be inertial masses such as heavy suspended ballast plates, sea-floor anchors or a fixed dead-weight or pile as shown.

Wave Profile Devices

Wave Energy Devices

The pitching and heaving of the waves causes a relative motion between an absorber and reaction point. The left hand wave energy device above, uses a heavy ballast plate suspended below the floating buoy. The buoy is prevented from floating away by a mooring line attached to a sea-floor anchor. This mooring line allows the point absorber to operate offshore in deeper waters.

As the buoy bobs up-and-down in the waves, a oscillatory mutual force reaction is generated between the freely moving absorber and the heavy plate causing a hydraulic pump in between to rotate a generator producing electricity. The middle wave energy device operates in a similar manner to the previous floating buoy device.

The difference this time is that the freely heaving buoy reacts against a fixed reaction point such as a fixed dead-weight on the ocean floor. As this type of point absorber is bottom mounted, it is operated in shallower near shore locations.

The third device is an example of a linear absorber (wave attenuator) which floats on the surface of the water. It to is tethered to the ocean floor so that it can swing perpendicularly towards the incoming waves. As the waves pass along the length of this snake like wave energy device, they cause the long cylindrical body to sag downwards into the troughs of the waves and arch upwards when the waves crest is passing.

The Pelamis Wave Energy Converter

Wave Energy Devices Video

Connecting joints along the body of the device flex in the waves exerting a great deal of force which is used to power a hydraulic ram at each joint. The hydraulic ram drives oil through a hydraulic motor which drives a generator, producing the electricity.

This method of wave energy conversion is currently being used by a device called the Pelamis Wave Energy Converter developed by the “Pelamis Wave Power” company (please watch the video for more information). One advantage of the Pelamis design is that several offshore devices can be connected and linked together to the shoreline through a single submersible underwater cable and as it responds and flexes to the gentle movement of the waves, it has the potential to produce a steady and constant supply of electrical power.

Oscillating Column Wave Energy Devices

The Oscillating Water Column, (OWC) is a popular shoreline wave energy device normally positioned onto or near to rocks or cliffs which are next to a deep sea bottom. They consist of a partly submerged hollow chamber fixed directly at the shoreline which converts wave energy into air pressure.

The structure used to capture the waves energy could be a natural cave with a blow hole or a man made chamber or duct with a wind turbine generator located at the top well above the waters surface. Either way, the structure is built perpendicular to the waves with part of the ocean surface trapped inside the chamber which itself is open to the sea below the water line. The constant ebbing and flowing motion of the waves forces the trapped water inside the chamber to oscillate in the vertical up-down direction.

Oscillating Wave Column

Oscillating Wave Column

As the incident waves outside enter and exit the chamber, changes in wave movement on the opening cause the water level within the enclosure to oscillate up and down acting like a giant piston on the air above the surface of the water, pushing it back and forth. This air is compressed and decompressed by this movement every cycle. The air is channelled through a wind turbine generator to produce electricity as shown.

The type of wind turbine generator used in an oscillating water column design is the key element to its conversion efficiency. The air inside the chamber is constantly reversing direction with every up-and-down movement of the sea water producing a sucking and blowing effect through the turbine. If a conventional turbine was used to drive the attached generator, this too would be constantly changing direction in unison with the air flow. To overcome this problem the type of wind turbine used in oscillating water column schemes is called a Wells Turbine.

The Wells turbine has the remarkable property of rotating in the same direction regardless of the direction of air flow in the column. The kinetic energy is extracted from the reversing air flow by the Wells turbine and is used to drive an electrical induction generator. The speed of the air flow through the wells turbine can be enhanced by making the cross-sectional area of the wave turbines duct much less than that of the sea column.

As with other wave energy converters, oscillating wave column technology produces no greenhouse gas emissions making it a non-polluting and renewable source of energy, created by natural transfer of wind energy through a wells turbine. The advantage of this shoreline scheme is that the main moving part, the turbine can be easily removed for repair or maintenance because it is on land. The disadvantage though is that, as with the previous wave energy devices, the oscillating wave columns output is dependent on the level of wave energy, which varies day by day according to the season.

Capture Wave Energy Devices

A Wave Capture Device also known as a Overtopping Wave Power Device, is a shoreline to near shore wave energy device that captures the movements of the tides and waves and converts it into potential energy. Wave energy is converted into potential energy by lifting the water up onto a higher level. The wave capture device, or more commonly an overtopping device, elevates ocean waves to a holding reservoir above sea level.

The overtopping wave energy converter works in much the same way as an impoundment type hydroelectric dam works. Sea water is captured and impounded at a height above sea level creating a low head situation which is then drained out through a reaction turbine, usually a Kaplan Turbine generating electricity as shown.

Capture Wave Energy Devices

Wave Capture Device

The basic impoundment structure can be either fixed or a floating structure tethered to the sea bed. The wave overtopping device uses a ramp design on the device to elevate part of the incoming waves above their natural height.

As the waves hit the structure they flow up a ramp and over the top (hence the name “overtopping”), into a raised water impoundment reservoir on the device in order to fill it. Once captured, the potential energy of the trapped water in the reservoir is extracted using gravity as the water returns to the sea via a low-head Kaplan turbine generator located at the bottom of the wave capture device.

Other such wave capture devices are located at the shoreline were the waves are channelled along a horizontal man made channel. This channel is funnel shaped which is wide towards the sea where the waves enter and gradually narrows towards an impoundment reservoir at the other end.

As the waves propagate along the narrowing channel, the wave height is lifted due to the funnelling effect to a level exceeding the horizontal upper edge of the channel wall, excess water from the wave is allowed to spill into a confined basin above the normal sea level. Since the water is now at a height above the sea level, the potential energy of the water trapped in the basin is then extracted by draining the water back to the sea through a low-head Kaplan turbine as before.

We now know how wave energy works and one of the main advantages of “wave energy devices”, is that besides the generating turbine there are no moving parts. Unfortunately, shoreline overtopping schemes have a relatively low power output due to their low head and are only suitable for sites where there is a deep water shoreline and a low tidal range of less than about a metre. To overcome some of these limitations, floating offshore capture devices have been developed, but they too require sufficient wave power to fill the impoundment reservoir.

We have seen above, some of the wave energy devices which are currently being used to extract electrical energy from wave energy. Mother nature provides a large supply of renewable wave energy every day and the technology already exists for extraction of this free energy but there are many technical challenges to be solved with the main barrier preventing wave energy from being a common form of power generation is the actual energy carrier itself: “the sea”.

The capture of wave energy has to face various problems. For example, wave energy devices are exposed to hard weather conditions, with some devices already been destroyed by the forces of tides and strong storms. Accessibility, maintenance and repair can also be costly, with the typical efficiency of a wave energy device at the moment being only about 30%.

However, if the technology and efficiencies are improved offshore wave energy can provide many advantages compared to other forms of renewable energy sources. One of its main advantages is that wave energy is generally considered to provide a clean source of renewable energy with limited negative environmental impacts with very low or zero CO2 emissions.

Sea waves have high energy densities, the highest among renewable energy sources with the natural seasonal variability of wave energy following the electricity demand in temperate climates securing energy supplies in remote regions. Wave energy also has negligible land use and large scale implementation of wave power technologies could help stimulate declining shipbuilding and dockyard industries that could help fabricate these metal bodied wave energy devices.

For more information about the different “Wave Energy Devices” available, or how to generate your own electricity using the power of the sea, or obtain more tidal energy information about the various tidal energy systems available, or to explore the advantages and disadvantages of wave power, then Click Here to order your copy from Amazon today about ocean, tidal and wave energy, the energy revolution from the sea.
